PMC Motorsport Custom flywheel
GM Chevrolet V8 LS - BMW M57N M57N2 GS6-53DZ HGU HGK / BMW N54 GS6-53BZ 6-speed - 240mm / 9.45"
Aluminum custom flywheel designed to connect the GM Chevrolet V8 LS engine to the BMW transmission.
What sets us apart:
The lightweight aluminium flywheel has a replaceable cast iron friction surface, each unit is carefully checked and balanced before shipment
We use a measuring arm and a high-quality 3D scanner in the design process
Thanks to the use of a measuring arm during the design process and the use of precision CNC machines - the adapter ensures perfect concentricity of the engine and gearbox
State-of-the-art CNC machinery and qualified staff.
Certified materials
Matching engines:
GM 5.7 Liter V8 Small Block Chevrolet LS1 5.7L / 346 cu. in. (1997-2005)
GM 6.0 Liter V8 Small Block Chevrolet LS2 6.0L / 364 cu. in. (2005-2009)
Corvette C5
Chevrolet SSR
Chevrolet Trailblazer SS
Cadillac CTS-V
Pontiac GTO
Saab 9-7X Aero
GM 6.2 Liter V8 Small Block Chevrolet LS3 6.2L / 376 cu. in.(2007-)
Chevrolet Corvette
Corvette Grand Sport
Chevrolet Camaro SS
Pontiac G8 GXP
GM 5.7 Liter V8 Small Block Chevrolet LS6 5.7L / 346 cu. in. (2001-2005)
GM 7.0 Liter V8 Small Block Chevrolet LS7 7.0L / 427 cu. in. (2006-2015)
Chevrolet Corvette Z06
Chevrolet Camaro Z/28
GM 6.0 Liter V8 Small Block L76 6.0L / 364 cu. in. (2007-2009)
Chevrolet Avalanche
Chevrolet Silverado
Chevrolet Suburban 1500
GMC Sierra
GMC Yukon XL
Holden Commodore
Pontiac G8
Matching gearboxes:
BMW M57N2 23.00 7565213 ZF GS6-53DZ HGU (THGU) 6-speed 1067 010 014 ZF 1067 401 116 1067401116 BMW OEM 23 00 7 571 420 / 23 00 7 560 725
BMW E90 325D 330D E90N 325D M57N2 E91 325D 330D E91N 325 M57N2 E92/e93 325D 330D M57N2
BMW M57N2 23.00 753 9000 ZF GS6-53DZ HGK (THGK) 6-speed 1067 010 004 ZF 1067 401 116 1067401116
BMW E90 325D 330D E90N 325D M57N2 E91 325D 330D E91N 325 M57N2 E92/e93 325D 330D M57N2
BMW N54 23.00 7565215 ZF GS6-53BZ HGX (THGX) 6-speed 1067 010 016 ZF 1067 401 127 1067401127 BMW OEM 23 00 7 571 423 / 23 00 7 567 242 BMW E60 535i E90 335i N54
BMW N54 23.00 7581859 ZF GS6-53BZ JGK (TJGK) 6-speed 1067 010 019 ZF 1067 401 127 1067401127 BMW OEM 23 00 7 581 860 BMW E82 135i N54 E88 135i N54
Installation instructions
An adapter is required to connect the engine to the gearbox.
Use the flywheel / rim from the automatic version o
Tighten the flywheel with the same torque as the OE.
The bearing and clutch paw remain from your gearbox. If you have a bearing with two height positions - use the 28.5mm position
